Duplex Slitter Shear With Automatic Stacker For Cutting Tinplate
Stripe
Product description:
The production process begins with the decoiling machine, which
unrolls the tinplate stripe and feeds it into the leveling machine.
The leveling machine flattens the stripe and ensures that it is
consistent and flat. The flattened stripe is then fed into the
slitting machine, which slices the stripe into narrower strips of
the desired width.
The strips are then fed into the shear machine, which cuts the
strips into sheets of the desired length. The automatic stacking
machine then stacks the cut sheets for further processing.
The advantages of using a duplex slitter shear with automatic
stacker for cutting tinplate stripes include increased production
efficiency, improved product quality, and reduced labor costs.
These machines can handle a large volume of production, with
minimal manual intervention required.
Product parameter:
| Name | Duplex Slitter |
| Feeding Speed of Feeder Machine | 0-32sheets/min |
| Iron Cutting Speed | 0～59m/min |
| Thickness of Cutting Iron Sheet | 0.15~0.5mm |
| Application Range of Cutting Iron Sheet | 600～1150mm |
| Machine size | L5900×W1750×H1750mm |
| Total Unit Power | 5.5kw |
| Net weight | 6700kg |
Product picture:
